DETAIL INFORMATION

1. MATERIAL:

HOUSING: HIGH THERMOPLASTIC, UL94V-0, BLACK

CONTACTS: T=0.35mm PHOS-BRONZE, 30u" GOLD PLATING ON CONTACT AREA, NICKEL UNDERPLATING OVERALL

SOLDER PIN: T=0.35*0.45mm COPPER, NICKEL PLATING, TIN PLATING ON ALL AREA

SHIELD: T=0.20mm COPPER ALLOY, NICKEL PLATING

2. NUMBER OF PORT: 1*1

3.SPEED: 10G

4. LED: GREEN/YELLOW

5. OPERATING TEMPERATURE: -40°C~+85°C

6. INSERTION FORCE: 4 POUNDS MAX.

EXTRACTION FORCE: 4 POUNDS MAX.

7. DURABILITY: 750 MATING CYCLED MIN.

8. CAVITY CONFORMS TO FCC RULES AND REGULATIONS PART 68, SUBPART F.
