DETAIL INFORMATION

1. MATERIAL:

HOUSING: HIGH THERMOPLASTIC, UL94V-0, BLACK

CONTACTS: T=0.30mm PHOS-BRONZE, 30u" GOLD PLATING ON CONTACT AREA, NICKEL UNDERPLATING ON ALL AREA

SOLDER PIN: T=0.30*0.40mm COPPER, NICKEL PLATING, TIN PLATING ON ALL AREA

SHIELD: T=0.20mm COPPER ALLOY, NICKEL PLATING

2. NUMBER OF PORT: 1*2

3.SPEED: 10G

4. OPERATING TEMPERATURE: -40°C~+85°C

5. INSERTION FORCE: 4 POUNDS MAX.

EXTRACTION FORCE: 4 POUNDS MAX.

6. DURABILITY: 750 MATING CYCLED MIN.

7. CAVITY CONFORMS TO FCC RULES AND REGULATIONS PART 68,

SUBPART F.
