Home » Products » RJ45 TRANSFORMER » RJ45 TRANSFORMER » RJ45 8P12C, W/10G TRANSFORMER, W/LIGHT PIPE, SHIELDED
RJ45 TRANSFORMER » RJ45 TRANSFORMER
  • RJ45 8P12C, W/10G TRANSFORMER, W/LIGHT PIPE, SHIELDED

PART NO. 8-7-RJS1x11010G

DETAIL INFORMATION

1. MATERIAL:

HOUSING : NYLON POLYESTER, UL94V-0, MIXED GLASS FIBER, STANDARD COLOR-BLACK

CONTACTS : 0.35mm THICK PHOS-BRONZE PLATED WITH 30u" GOLD, NICKEL UNDERPLATE ON ALL AREA

SOLDER PIN : COPPER 0.35X0.45mm, PLATED WITH NICKEL, TIN PLATING IN ALL AREA

SHIELD : 0.20mm THICK COPPER ALLOY, PLATED WITH NICKEL.

LIGHT PIPE : POLYCARBONATE

2. NUMBER OF PORT: 1*1

3.SPEED: 10G

4. OPERATING TEMPERATURE: -40°C~+85°C

5. INSERTION FORCE: 4 POUNDS MAX.

  EXTRACTION FORCE: 4 POUNDS MAX.

6. DURABILITY: 750 MATING CYCLED MIN.

7. CAVITY CONFORMS TO FCC RULES AND REGULATIONS PART 68, SUBPART F.
