Home » Products » RJ45 TRANSFORMER » RJ45 TRANSFORMER » RJ45 1X1, W/5G TRANSFORMER AND 4PPoE, W/LED, SHIELDED
RJ45 TRANSFORMER » RJ45 TRANSFORMER
  • RJ45 1X1, W/5G TRANSFORMER AND 4PPoE, W/LED, SHIELDED

PART NO. 8-7-RJS1x1115G

DETAIL INFORMATION

1. MATERIAL:

HOUSING: HIGH THERMOPLASTIC, UL94V-0, COLOR-BLACK

CONTACTS: T=0.35MM PHOS-BRONZE, 6U" GOLD PLATING ON CONTACT AREA, NICKEL UNDERPLATING OVERALL

SHIELD: T=0.20MM COPPER ALLOY, NICKEL PLATING7. SPEED: 5G

2. LED: GREEN

3. NUMBER OF PORT: 1*1

4. SPEED: 5G

5. OPERATING TEMPERATURE: 0°C~+70°C

6. MATING FORCE: 4 POUNDS MAX.

  UNMATING FORCE: 4 POUNDS MAX.

7. DURABILITY: 750 MATING CYCLED MIN.

8. CAVITY CONFORMS TO FCC RULES AND REGULATIONS PART 68, SUBPART F.
